Locatingconnectorsontherearofyourcomputer
Figure2“Rearconnectorlocations”onpage5showsthelocationsoftheconnectorsontherearofyour
computer.Someconnectorsontherearofyourcomputerarecolor-codedtohelpyoudeterminewhereto
connectthecablesonyourcomputer.
Figure2.Rearconnectorlocations
1Security-lockslot
7acpoweradapterconnector
2PS/2keyboardconnector
8acpoweradaptercableloop
3Serialconnectors(4)
9Ethernetconnector
4VGAmonitorconnector
10Parallelconnector
5DisplayPortconnector
11PS/2mouseconnector
6USB2.0connectors(2)
ConnectorDescription
DisplayPortconnector
Usedtoattachahigh-performancemonitor,adirect-drivemonitor,orotherdevices
thatuseaDisplayPortconnector.
Ethernetconnector
UsedtoattachanEthernetcableforaLAN.
Note:TooperatethecomputerwithinFCCClassBlimits,useaCategory5Ethernet
cable.
PS/2keyboardconnectorUsedtoattachakeyboardthatusesaPS/2keyboardconnector.
PS/2mouseconnectorUsedtoattachamouse,atrackball,orotherpointingdevicesthatuseaPS/2
mouseconnector.
ParallelconnectorUsedtoattachaparallelprinterorotherdevicesthatusea25-pinparallelconnector.
Chapter1.Productoverview5
