Lenovo ThinkPad E15 User Manual

Chapter 6. CRU replacement
What are CRUs
Customer Replaceable Units (CRUs) are parts that can be upgraded or replaced by the customer. The
computers contain the following types of CRUs:
• Self-service CRUs: Refer to parts that can be installed or replaced easily by customer themselves or by
trained service technicians at an additional cost.
• Optional-service CRUs: Refer to parts that can be installed or replaced by customers with a greater skill
level. Trained service technicians can also provide service to install or replace the parts under the type of
warranty designated for the customer’s machine.
If you intend on installing a CRU, Lenovo will ship the CRU to you. CRU information and replacement
instructions are shipped with your product and are available from Lenovo at any time upon request. You
might be required to return the defective part that is replaced by the CRU. When return is required: (1) return
instructions, a prepaid shipping label, and a container will be included with the replacement CRU; and (2) you
might be charged for the replacement CRU if Lenovo does not receive the defective CRU within thirty (30)
days of your receipt of the replacement CRU. For full details, see the Lenovo Limited Warranty
documentation at
https://www.lenovo.com/warranty/llw_02.
Refer to the following CRU list for your computer.
Self-service CRUs
• ac power adapter
• Power cord
Optional-service CRUs
• Base cover assembly
• Memory module
• Hard disk drive*
• Hard disk drive bracket*
• Hard disk drive cable*
• M.2 solid-state drive*
• M.2 solid-state drive bracket*
• Speaker assembly
* for selected models
Disable Fast Startup and the built-in battery
Before replacing any CRU, ensure that you disable Fast Startup first and then disable the built-in battery.
To disable Fast Startup:
1. Go to Control Panel and view by Large icons or Small icons.
2. Click Power Options, and then click Choose what the power buttons do on the left pane.
3. Click Change settings that are currently unavailable at the top.
© Copyright Lenovo 2020 35

Lenovo ThinkPad E15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS), Aluminium
Display diagonal	15.6 \
Anti-glare screen	Yes
Display brightness	250 cd/m²
Operating system language	English
Operating system architecture	64-bit
Keyboard layout	QWERTY
Processor cache	8 MB
Processor cores	4
Processor model	i7-10510U
Processor family	Intel® Core™ i7
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4.9 GHz
Configurable TDP-up frequency	2.3 GHz
Configurable TDP-down frequency	0.8 GHz
Motherboard chipset	Intel SoC
Memory slots	1x SO-DIMM
Internal memory	16 GB
Internal memory type	DDR4-SDRAM
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
SSD form factor	M.2
Total storage capacity	512 GB
Number of SSDs installed	1
Battery capacity	45 Wh
Battery life (max)	12.2 h
AC adapter power	65 W
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
Cable lock slot type	Kensington
Trusted Platform Module (TPM) version	2.0
Audio chip	Synaptic CX11880
Audio system	Dolby Advanced Audio
Speaker power	2 W
Number of built-in speakers	2
Privacy type	Privacy shutter
Front camera resolution	1270 x 720 pixels
WWAN	Not installed
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN data rates	100, 1000 Mbit/s
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS, TCO
HDMI version	1.4b
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	245 mm
Width	368 mm
Height	18.9 mm
Weight	1900 g
