Applyinglabelstothebasecover
ThenewbasecoverFRUisshippedwithakitcontaininglabelsofseveralkinds.
Thefollowingillustrationshowsthecorrectlocationofeachlabel.
7 843
6
521
15
19
18
21
20
22
17
16
14 9
11 101213
IftheWindowsCerticateofAuthentication(COA)label8isattachedtoapartthatisreplaced,returnthe
oldpartwiththelabelattachedtothecustomer,orprovidealettertothecustomerstatingwhatthelabel
wasoriginallyonthecomputerandwhatthelabelpartnumber,serialnumber,andproductkeywere.
Whenyoureplacethebasecover,applytheFCClabel
3andtheSerialnumberlabel4.
Thefollowinglabelsneedtobepeeledofffromtheoldbasecover,andneedtobeadheredtothenew
basecover.
1GEOlabelforTaiwanonly14SwissSIMICCIDlabel
2GEOlabel15ChinawirelessWANlabel
5WirelessWANMAClabel16SIRIMlabelorIndonesiaPOSTELlabel
6Ratinglabel
17BrazilANATELlabelfor3GwirelessWANcard
7JapanGEOlabel
18BrazilANATELlabelforBluetooth
9Non-encryptionlabel
19BrazilANATELlabelforwirelessLANcard
10Indonesiaratinglabel
20Chinaproductlabel
11IsraelhomologationlabelforwirelessLANcard
21ChinaGEOlabel
12IsraelhomologationlabelforBluetooth
22Assettag
13Israelhomologationlabelfor3GwirelessWANcard
IftheremovedcoverhastwoFCClabels,applybothtothenewbasecover.
