Unlockthebatterylatch1.Holdthebatterylockleverintheunlockedposition,andremovethebattery
pack2.
2
2
1
Wheninstalling:Installthebatterypackintotheslot.Ensurethatthebatterylatchisinthelockedposition.
1020Largebottomcover
Foraccess,removethisFRU:
•“1010Batterypack”onpage62
Removalstepsofthelargebottomcover
Loosenthescrews1andthenremovethelargebottomcover2.
1
1
1
2
Chapter9.RemovingorreplacingaFRU63
