Lenovo ThinkPad Edge E531 - 2040 Wireless Antenna Assembly and LCD Rear Cover Assembly

2040WirelessantennaassemblyandLCDrearcoverassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1030Smallbottomcover”onpage64
•“1040Opticaldriveorblankbezel”onpage65
•“1060Harddiskdriveassemblyorsolid-statedriveassembly”onpage67
•“1070WirelessWANcardorM.2solid-statedrive”onpage69
•“1080WirelessLANcard”onpage72
•“1090Backupbattery”onpage73
•“1110Keyboard”onpage76
•“1120Keyboardbezel”onpage82
•“1140Systemboardassembly”onpage85
•“1160LenovoOneLinkconnectorcover”onpage91
•“1170DC-inbracketandDC-inconnectorwithRJ45subcard”onpage91
•“1200LCDunit”onpage95
•“2010LCDbezelassembly”onpage101
•“2020LCDpanelandhinges”onpage102
RemovalstepsofthewirelessantennaassemblyandtheLCDrearcoverassembly
Note:ThewirelessWANantennaassemblyisonlyavailableinsomemodels.
ReleasetheantennacablesfromthecableguidesontheLCDrearcoverassembly.
1 1 1 1
2
2
2
2
11
