Note:ThewirelessWANantennaassemblyisonlyavailableinsomemodels.
3
3
Cablerouting:Whenyouinstallthewirelessantennaassembly,routethecablesasshowninthefollowing
illustration.
Attention:Whenyouroutethecables,ensurethattheyarenotsubjecttoanytension.Tensioncouldcause
thecablestobedamagedbythecableguides,orawiretobebroken.
Note:ThewirelessWANantennaassemblyisonlyavailableinsomemodels.
a b c d
Antennalocations
aWirelessLANAUXantenna(black)
bWirelessWANAUXantenna(blue)
cWirelessWANMAINantenna(red)
dWirelessLANMAINantenna(gray)
Chapter9.RemovingorreplacingaFRU107
