Lenovo ThinkPad Edge E531 - 1060 Hard Disk Drive Assembly or Solid-State Drive Assembly

Wheninstalling:
Note:Ifonlyonememorymoduleistobeinstalledonthecomputeryouareservicing,thememorymodule
mustbeinstalledininthelowermemoryslota(SLOT-0),nottheuppermemoryslotb(SLOT-1).
b
a
Insertthenotchedendofthememorymoduleintotheslotatanangleofabout20degrees.Pressthe
memorymodulermly,andpivotitdownwardsuntilitsnapsintoplace.Ensurethatthememorymoduleis
rmlyinstalledintheslotanddoesnotmoveeasily.
1060Harddiskdriveassemblyorsolid-statedriveassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
Attention:
•Donotdropthedriveorapplyanyphysicalshocktoit.Thedriveissensitivetophysicalshock.Improper
handlingcancausedamageandpermanentlossofdata.
•Beforeremovingthedrive,havetheusermakeabackupcopyofalltheinformationonitifpossible.
•Neverremovethedrivewhilethecomputerisoperatingorisinsuspendmode.
Chapter9.RemovingorreplacingaFRU67
