RemovalstepsofthewirelessWANcard
Instep1,unplugtheconnectorsbyusingtheantennaRFconnectorremovaltoolorpickuptheconnectors
withyourngersandgentlyunplugthemasshown.
1
2
1
Wheninstalling:PlugtheredcableintotheconnectormarkedMAIN,andthebluecableintotheconnector
markedAUXonthecard.
StepScrew(quantity)Color
Torque
2
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
3
