Miscellaneous parts
FRU P/N CRU
ID
Screw kit (including nylon-coated screws):
v M2.5 × 4.8 mm (black), bind-head (8)
v M2 × 4 mm (black), bind-head (14)
v M2 × 6 mm (black), bind-head (4)
v M2 × 12 mm (black), flat-head (17)
v M2 × 10 mm (black), flat-head (9)
v Hex stud (4)
v M2 × 18.9 mm, special shape (1)
v M3 × 3 mm (PHILLIPS/slotted) (1)
v M2 × 3 mm (silver), small flat-head (LCD
unit hinge) (8)
v Screw caps (not painted)
v Screw caps, square
v Screw caps, USB
v Screw caps, rear, oval
13N5168 N
Base miscellaneous parts:
v Cover, PC Card slot
v Spring, PC Card slot cover
v Rubber foot (rear)
v Rubber foot (front)
v Insulation, bottom
v Insulation sheet
v Insulation, louver
v Battery lock knob L
v Battery lock latch L
v Battery lock latch R
v Battery lock link
v Spring, battery lock
v Slide lever
v Slide lever spring
v Pull lever
v Pull lever spring
v Puller
v Sheet, HDD rubber 15
v Sheet, HDD rubber 14
v HDD shock absorber 14/15
v HDD shock absorber 14
v Security plate
v Shield, battery 14
v Shield, battery 15
13N5166 N
(continued)
Parts list
ThinkPad R50/R50p and R51 Series 217
