FRU P/N CRU
ID
14.1-in. LCD miscellaneous parts:
v (k) LCD latch assembly, 14 (L)
v (l) LCD latch, 14 (R)
v (m) Lower cable bush, 14
v (n) Upper cable bush, 14
v Finger, LCD FPC 14
v Screw caps (not painted)
v Screw caps, square
Note:
Italicized letters in parentheses are
references to the exploded view on page 188.
13N5169 N
15.0-in. LCD miscellaneous parts:
v (k) LCD latch assembly, 15 (L)
v (l) LCD latch, 15 (R)
v (m) Lower cable bush, 15
v (n) Upper cable bush, 15
v LCD FPC tape
v Finger, LCD FPC 15
v Screw caps (not painted)
v Screw caps, square
13N5170 N
System miscellaneous parts:
v (a) Cable, RJ11-docking connector on
system board
v (e) DC in cable
v (i) Bracket, I/O plate 14/15, CR
v (h) Bracket structure 14/15
v (b) Antenna cable guide
v (c) EMI spring, CDC
v Connector bag
v Blank cap, IEEE1394 connector
v Spacer, IEEE1394 connector, CR
v (j) Retainer, LCD cable 14/15, CR
v (g) Bracket, VGA connector 14, CR
v (g) Bracket, VGA connector 15, CR
v (f) Bracket, cable hook
v HDD connector retainer, CR
v Bracket M7 14, CR
v Bracket M7 15, CR
v (d) Heatsink M9 14
v (d) Heatsink M9 15, CR
v Ferrite core, RH
v Ferrite core, LH
v Bracket, joint 14, CR
v Bracket, joint 15, CR
v Cu tape, VGA cable
Note:
Italicized letters in parentheses are
references to the exploded view on page 140.
13R2875 N
(continued)
Parts list
ThinkPad R50/R50p and R51 Series 219
