4
5
Step
Screw
(quantity)
Color
T
orque
4
M2
×
6
mm,
bind-head,
nylon-coated
(1)
Black
0.245
Nm
(2.5
kgfcm)
Before
remove
the
IEEE
1394
cable,
remove
bracket
structure
5
.
(continued)
Removing
and
replacing
a
FRU
ThinkPad
R50/R50p
and
R51
Series
95
98
100
