• “1010 Bottom cover” on page 64
• “1020 Battery” on page 65
• “1030 Hard disk drive assembly, solid-state drive assembly, hard disk drive cable, or solid-state drive
cable” on page 65
• “1050 Keyboard” on page 68
• “1060 Base cover assembly” on page 70
• “2010 LCD unit” on page 89
• “2020 LCD bezel” on page 91
• “2030 LCD hinges” on page 92
Removal step of the LCD panel and LCD cable
Step Screw (quantity) Color Torque
1
M2 × 3 mm, flat-head, nylon-coated, small head (2) Black 0.196 Nm
(2 kgf-cm)
Chapter 9. Removing or replacing a FRU 93
To Next Page
