9.Notetheorientationofthenewbackplane.Carefullypressthenewbackplanestraightdownintothe
chassissothatitissecuredinplacebythetabs1onthechassisandthethreescrewholesinthenew
backplanearealignedwiththecorrespondingholesinthechassis.Then,installthescrewstosecure
thenewbackplaneinplace.
Figure102.Installingthebackplanefor2.5-inchharddiskdrives
10.Reinstallallthehot-swapharddiskdrivesanddummytrays(ifany)intheharddiskdrivecage.See
“Installingorreplacingahot-swapharddiskdrive”onpage128.
11.Refertoyournotetoconnectthecablestothenewbackplane.
12.Ifyouareinstructedtoreturntheoldhot-swapharddiskdrivebackplane,followallpackaging
instructionsanduseanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage162.
Replacingtherisercardassembly1
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage71.
Thistopicprovidesinstructionsonhowtoreplacetherisercardassembly1.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Toreplacetherisercardassembly1,dothefollowing:
Chapter6.Installing,removing,orreplacinghardware137
