Backplanefor2.5-inchharddiskdrives
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplanefor2.5-inchharddisk
drives.
Thefollowingillustrationsshowtheconnectorsonthebackplanefor2.5-inchharddiskdrives.
Figure26.Frontviewofthebackplanefor2.5-inchharddiskdrives
1Slot0fora2.5-inchharddiskdriveorsolid-state
drive
5Slot4fora2.5-inchharddiskdriveorsolid-statedrive
2Slot1fora2.5-inchharddiskdriveorsolid-state
drive
6Slot5fora2.5-inchharddiskdriveorsolid-statedrive
3Slot2fora2.5-inchharddiskdriveorsolid-state
drive
7Slot6fora2.5-inchharddiskdriveorsolid-statedrive
4Slot3fora2.5-inchharddiskdriveorsolid-state
drive
8Slot7fora2.5-inchharddiskdriveorsolid-statedrive
Figure27.Rearviewofthebackplanefor2.5-inchharddiskdrives
18-pinpowerconnector
3Mini-SASports0-3
2Mini-SASports4-74Opticaldrivepowerconnector
38ThinkServerHardwareMaintenanceManual
