Lenovo ThinkStation C20 Hardware Maintenance Manual

board.Connectoneendofthenewsignalcabletotheopticaldriveandtheotherendtoanavailable
SATAconnectoronthesystemboard.See“Locatingpartsandconnectorsonthesystemboard”
onpage71.
b.Locateanavailableve-wirepowerconnectorandconnectittothenewopticaldrive.
Figure26.Connectinganewopticaldrive
7.ReinstallthePCIcardholderintothechassisifyouhaveremovedit.See“Removingandreinstallingthe
PCIcardholder”onpage76.
8.Reinstallthefrontbezel.See“Removingandreinstallingthefrontbezel”onpage75.
9.Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage110.
Replacingtheheatsinkandfanassembly
Attention
Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafety
information”intheThinkStationSafetyandWarrantyGuidethatcamewithyourcomputer.Toobtainacopy
oftheThinkStationSafetyandWarrantyGuide,goto:
http://www.lenovo.com/support
CAUTION:
Theheatsinkandfanassemblymightbeveryhot.Turnoffthecomputerandwaitthree
toveminutestoletthecomputercoolbeforeremovingthecomputercover.
Thissectionprovidesinstructionsonhowtoreplacetheheatsinkandfanassembly.
Toreplacetheheatsinkandfanassembly,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandthecomputer.Then,disconnect
allpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtothecomputer.
2.Removethecomputercover.See“Removingthecomputercover”onpage74.
3.RemovethePCIcardholder.See“RemovingandreinstallingthePCIcardholder”onpage76.
4.Yourcomputersupportstwoheatsinkandfanassemblies.Locatetheheatsinkandfanassemblyyou
wanttoreplace.See“Locatingcomponents”onpage70.
5.Dependingontheheatsinkandfanassemblyyouwanttoreplace,dooneofthefollowing:
•Ifyouarereplacingheatsinkandfanassembly1,goto6onpage91.
•Ifyouarereplacingheatsinkandfanassembly2,dothefollowing:
a.Removetheopticaldrive.See“Replacingtheopticaldrive”onpage88.
90ThinkStationHardwareMaintenanceManual

Lenovo ThinkStation C20 Specifications

General

HDD capacity	500 GB
Internal memory	8 GB
Memory clock speed	1333 MHz
Processor cache	12 MB
Processor frequency	2.4 GHz
Processor front side bus	1066 MHz
Power supply	800 W
Plug and Play	Yes

Weight and Dimensions

Depth	444 mm
Width	130 mm
Height	427 mm
