Front view without bezel
Figure 2. Front view of models with 12 drive bays
Figure 3. Front view of models with 24 drive bays
Table 3. Components on the front of the system (without bezel)
1 Chassis power LED 2 Chassis attention LED (front) 3 Chassis location LED (front)
4 Shelf ID digital display 5 Shelf ID change button 6 Hot-swap drive bays (12/24)
7 Drive activity LED 8 Drive status LED
Rear view
The rear of the system provides access to several connectors and components, including the power supplies
and various connectors.
6
ThinkSystem DM3000x and DM5000x Hardware Installation and Maintenance Guide
