SP Redirection
• Enable
• Disable
This option is only displayed while “Console Redirection”,
“COM Port 1” and “COM Port 2” set to [Enable]. It allows
you to choose which COM port to have the redirection.
Note: Only show when set Console Redirection to
Enable.
Disable is the default setting.
Legacy OS/Option ROM
Display
• COM Port 2
• COM Port 1
Select a COM port to display redirection of Legacy OS
and Legacy OPROM Messages.
COM Port 1 is the default setting.
COM1 Settings N/A Settings required for serial connections used for
asynchronous start-stop communication.
COM1 Baud Rate
• 115200
• 57600
• 38400
• 19200
• 9600
Control the connection speed between the host and
remote system. 115200 is the default setting.
COM1 Data Bits
• 8
• 7
Set the number of Data bits in each character.
COM1 Parity
• None
• Odd
• Even
Select parity bit in each character to be [None], [Odd], or
[Even]. [None] means that no parity bit is sent at all. None
is the default setting.
COM1 Stop Bits
• 2
• 1
Set Stop Bits. Stop Bits sent at the end of every character
allow the signal receiver to detect the end of a character
and to resynchronize with the character stream.
COM1 Terminal Emulation
• VT100
• VT-UTF8
• ANSI
Select [VT100] only if the remote emulator does not
support ANSI text graphics. Consult the emulator
documentation for more information. ANSI is the default
setting.
COM1 Active After Boot
• Enable
• Disable
When [Disable] is selected, then Legacy Console
Redirection is disabled before booting to legacy OS.
When [Enable] is selected, then Legacy Console
Redirection is enabled for legacy OS. "COM1 Active after
Boot" and "COM2 Active after Boot" settings go together,
and if you change one setting, it automatically changes
the other. Disable is the default setting.
COM1 Flow Control
• Disable
• Hardware
Select [Hardware] only if the remote emulator support and
is using hardware flow control. Consult the emulator
documentation for more information. Disable is the
default setting.
COM2 Settings N/A Settings required for serial connections used for
asynchronous start-stop communication.
14 ThinkSystem Server with Intel Xeon SP (1st, 2nd Gen) UEFI Manual
