Table 8. Network details
Item
Options
Description
Global Network Settings N/A Specify global network settings.
iSCSI Settings N/A Configure the iSCSI parameters.
Network Stack Settings N/A Specify Network Stack Settings.
Network Boot Settings N/A Configure the network boot parameters
Network Device List
N/A Specify network device list.
iSCSI Settings
Item Options Description
iSCSI Initiator Name
Iqn.1986-03.com.
example
The worldwide unique name of iSCSI Initiator. Only IQN
format is accepted. Range is from 4 to 233.
Add an Attempt
N/A
Add an Attempt
List of Attempts.
Note: Only appears when
attempts exist. Selecting an item
will lead to Attempt Configuration
page in 2.1.10.1.1.1.
N/A
MAC: XX:XX:XX:XX:XX:XX, PFA: Bus XX | Dev XX | Func
XX, “iSCSI Mode”: [%s1], “Internet Protocol”: [%s2]
Exact value will be different depends on the attempt
settings.
%s1 will be option name for iSCSI Mode.
%s2 will be the setting name for Internet Protocol.
Delete Attempts N/A Delete one or more attempts
Change Attempt Order N/A Change the order of Attempts using +/- keys. Use arrow
keys to select the attempt then press +/- to move the
attempt up/down in the attempt order list.
Network Stack Settings
Item
Options
Description
Network Stack
• Enable
• Disable
Enable/Disable UEFI Network Stack. Enable is the default
setting.
IPv4 PXE Support
• Enable
• Disable
Enable IPv4 PXE Boot Support. If disabled IPv4 PXE boot
option will not be created. Enable is the default setting.
IPv4 HTTP Support
• Enable
• Disable
Enable IPv4 HTTP Boot Support. If disabled IPv4 HTTP
boot option will not be created. Enable is the default
setting.
IPv6 PXE Support
• Enable
• Disable
Enable IPv6 PXE Boot Support. If disabled IPv6 PXE boot
option will not be created. Enable is the default setting.
IPv6 HTTP Support
• Enable
• Disable
Enable IPv6 HTTP Boot Support. If disabled IPv6 HTTP
boot option will not be created. Disable is the default
setting.
Chapter 3. System configuration and boot management 23
