Subnet Mask
x.x.x.x
Enter Subnet Mask in dotted-decimal notation.
When entering an invalid IP address:
• ERROR
• Invalid Input Range
• Ok
Default Gateway
x.x.x.x
Enter Default Gateway in dotted-decimal notation.
When entering an invalid IP address:
• ERROR
• Invalid Input Range
• Ok
IP6
• Enable
• Disable
Enable/Disable IPv6 support on management port.
Local Link Address N/A
VLAN Support
• Enable
• Disable
Enable VLAN Support to specify the 802.1q VLAN ID on
the management port network device.
Advanced Setting for BMC
Ethernet
N/A Advanced Setting for BMC Ethernet.
Advanced Settings for BMC Ethernet
Item Options Description
Autonegotiation
• No
• Yes
Choose whether the Data rate and Duplex network
settings are configurable or not.
Data rate Autonegotiation is
‘Yes’:
Auto
Autonegotiation is
‘No’:
100 Mb (Ethernet)
10 Mb (Ethernet)
Amount of data to be transferred per second over LAN
connection.
Chapter 3. System configuration and boot management 51
