Ports Front: One VGA video port. Two USB 2.0 ports or one USB 2.0 and one USB 3.0 port, model
dependent. The first USB 2.0 port can be configured to support local systems management by
using the XClarity Administrator mobile app on a mobile device connected via a USB cable.
Rear: Two USB 3.0 ports, one VGA video port, one DB-9 serial port, and one RJ-45 XClarity
Controller (XCC) systems management port. The serial port can be shared with the XCC for serial
redirection functions.
Internal: Optional M.2 adapter in dedicated slot supporting one or two M.2 drives (for OS boot
support, including hypervisor support).
Cooling Six N+1 redundant non-hot-swap 60 mm fans (all six standard). One additional fan connected to
each of the two upper riser units. One additional fan integrated in each of the two power supplies.
Power supply Up to two hot-swap redundant AC power supplies (all 80 PLUS Platinum certification): 750 W,
1100 W, 1600 W and 2000 W AC options, supporting 220 V AC. 750 W and 1100 W options also
support 110V input supply. In China only, all power supply options support 240 V DC. Second
power supply requires either Processor and Memory Expansion Tray or a power interposer card.
Video G200 graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity
Controller. Maximum resolution is 1920x1200 32bpp at 60Hz.
Hot-swap
parts
Drives and power supplies.
Systems
management
XClarity Controller embedded management, XClarity Administrator centralized infrastructure
delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power
management. XClarity Controller Advanced standard with the SR860; XClarity Controller
Enterprise optional with software license upgrade. Light path diagnostics for local failure detection
and reporting, with optional LCD diagnostics pull-out panel.
Security
features
Power-on password, administrator's password, Trusted Platform Module (TPM), supporting TPM
1.2 or TPM 2.0. In China only, optional Trusted Cryptographic Module (TCM). Lockable top cover.
Optional lockable front security bezel.
Operating
systems
supported
Microsoft Windows Server 2012 R2, 2016; RHEL 6 & 7 x64; SLES 11 & 12 x64; VMware ESXi 6.0,
6.5
Limited
warranty
Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty
with 9x5 next business day (NBD).
Service and
support
Optional service upgrades are available through Lenovo Services: 4-hour or 2-hour response time,
6-hour fix time, 1-year or 2-year warranty extension, software support for Lenovo hardware and
some third-party applications. Actual offering may depend on the country where the server is
installed and is subject to change.
Dimensions Height: 175mm (6.9 in.), width with rack handle: 482mm (19 in.), width without rack handle:
447mm (17.6 in.), depth: 766mm (30.1 in)
Weight Maximum: 39.8 kg (87.7 lb)
Components Specification
The SR860 servers are shipped with the following items:
ThinkSystem Friction Rail kit
Documentation flyer
Power cords (model and region dependent)
