Note: NVMe PCIe SSDs support informed hot removal and hot insertion, provided the operating
system supports PCIe SSD hot-swap.
Table 20. M.2 drives
Part number Feature Description
Maximum
supported
M.2 SSDs - 6 Gb SATA - Enterprise Entry (<3 DWPD)
7N47A00129 AUUL ThinkSystem M.2 CV1 32GB SATA 6Gbps Non-Hot-Swap SSD 2
7N47A00130 AUUV ThinkSystem M.2 CV3 128GB SATA 6Gbps Non-Hot-Swap SSD 2
Internal backup units
The server does not support any internal backup units, such as tape drives or RDX drives.
Optical drives
The server does not support an internal optical drive.
An external USB optical drive is available, listed in the following table.
Table 21. External optical drive
Part number Feature code Description
7XA7A05926 AVV8 ThinkSystem External USB DVD RW Optical Disk Drive
I/O expansion options
The SR860 supports up to 13 PCIe slots including slots reserved for a LOM Ethernet adapter and an M.2
adapter.
Six slots are on the system board and three (slots 5-7) are through a lower riser card. Slots 1 & 2 and 14 &
15 are via upper riser cards that connect through slots 3 and 13 respectively.
Slots 1-13 available with 2 processors; slots 14 & 15 require 4 processors.
The following figure shows the locations of the externally accessible PCIe slots.
