Lenze AC Tech ESV113N04TXD User Manual

8
SV01M
Technical Data
2.3 Ratings
120V / 240VAC Models
Mains = 120V Single Phase (1/N/PE) (90...132V), 240V Single Phase (2/PE) (170...264V); 48...62Hz
Type
Power Mains Current Output Current Heat Loss (Watts)
Hp kW
120V
A
240V
A
Cont (I
n
)
A
Max I
%
N1/IP31 N4X/IP65
No filter
N4X/IP65
W/ filter
ESV251--1S-- 0.33 0.25 6.8 3.4 1.7 200 24
ESV371--1S-- 0.5 0.37 9.2 4.6 2.4 200 32 32
ESV751--1S-- 1 0.75 16.6 8.3 4.2 200 52 41
ESV112--1S-- 1.5 1.1 20 10.0 6.0 200 74 74
NOTES:
Output Current: The Output Current Maximum (%) is a percentage of the Output Current Continuous Amps (In) rating
and is adjustable in parameter P171.
240VAC Models
Mains = 240V Single Phase (2/PE) (170...264V); 48...62Hz
Type
Power Mains Current Output Current Heat Loss (Watts)
Hp kW
240V
A
Cont (I
n
)
A
Max I
%
N1/IP31 N4X/IP65
No filter
N4X/IP65
W/ filter
ESV251--2S-- 0.33 0.25 3.4 1.7 200 20
ESV371--2S-- 0.5 0.37 5.1 2.4 200 30
ESV751--2S-- 1 0.75 8.8 4.2 200 42
ESV112--2S-- 1.5 1.1 12.0 6.0 200 63
ESV152--2S-- 2 1.5 13.3 7.0 200 73
ESV222--2S-- 3 2.2 17.1 9.6 200 97
240V Single Phase (2/PE) (170...264V), 240V Three Phase (3/PE) (170...264V); 48...62Hz
Type
Power Mains Current Output Current Heat Loss (Watts)
Hp kW
1~ (2/PE)
A
3~ (3/PE)
A
Cont (I
n
)
A
Max I
%
N1/IP31 N4X/IP65
No filter
N4X/IP65
W/ filter
ESV371--2Y-- 0.5 0.37 5.1 2.9 2.4 200 27 26
ESV751--2Y-- 1 0.75 8.8 5.0 4.2 200 41 38
ESV112--2Y-- 1.5 1.1 12.0 6.9 6.0 200 64 59
ESV152--2Y-- 2 1.5 13.3 8.1 7.0 200 75 69
ESV222--2Y-- 3 2.2 17.1 10.8 9.6 200 103 93
