6.2 Repair
6.2.1 Opening the PC housing
0
0
0
0
0
0
1
CPC5100-003
How to remove the housing cover:
1. Loosen the six screws .
2. Lift the housing cover  upwards.
How to place the housing cover on the housing again:
1. Carefully place the housing cover  on the housing.
2. Tighten the six screws .
