Lenze E82ZAFSC010 - Page 25

EDK82ZAFSC−010 DE/EN/FR 6.1
25

ausklappbild−DUMMY_NUM_Reset
E82ZAFS010A
E82ZAFSC010function module

Switch for the configuration of the analog input (terminal X3/8) 43

Digital and analog inputs and outputs, plug connector X3 41

Nameplate 34
0Fig. 0Tab. 0
