Mechanical installation 3
EDKMF2133 DE/EN/FR 4.0
45
H1_MechINS-MechInst
3 Mechanical installation
2102LEC014
ƒ Plug the communication module onto the basic device (here: 8200 vector).
ƒ Screw the communication module to the basic device to ensure a good
PE connection.
Note!
For the internal supply o f the communication module through the 8200 vector
frequency inverter, the jumper in the interface opening must be adapted
(see fig. above). Please observe the notes (51) .
