Lenze EPL 10200 Series - Terminal strips - overview

Terminal strips - overview
3

MA DrivePLC DE/EN/FR 1.0
7
plc001
Abb. 1-17
0 Instrument seen from above
X1 DC voltage supply
X2 Digital outputs
X3 Digital inputs
1 Instrument seen from below
X4 Analog inputs/outputs
X5 System bus (CAN)
