System bus (CAN) with Ser vo PLC & Drive PLC
Configuration
3-8
l
PLC-Systembus EN 1.1
3.10.3 Reaction to system bus error messages
Overview of the system bus error sources detected by the PLC and the possible settings for the
individual reactions:
Error message Possible settings / Reaction
Display Error
no.
Meaning TRIP Message Warning Fault/QS
P
Off Code
CE1 62 Communication error CAN1_IN
(time mo nitoring can be set via C0357/1)
ü - ü - · C0591
CE2 63 Communication error CAN2_IN
(time mo nitoring can be set via C0357/2)
ü - ü - · C0592
CE3 64 Communication error CAN3_IN
(time mo nitoring can be set via C0357/3)
ü - ü - · C0593
CE4 65 BUS OFF state
(too many faulty telegrams were received)
ü - ü - · C0595
· Default setting üpossible - not possible
