11
Commissioning
4.2 Electronic programming module (EPM)
The EPM contains the controller’s memory. Whenever parameter settings are changed,
the values are stored in the EPM. It can be removed, but must be installed for the
controller to operate (a missing EPM will trigger an fault). The controller ships with
protective tape over the EPM that can be removed after installation.
An optional EPM Programmer (EEPM1RA) is available that allows: the controller to be programmed without
power; OEM settings to be default settings; fast copying of EPMs when multiple controllers require identical
settings. It can also store up to 60 custom parameter les for even faster controller programming.
Tmd007
4 Commissioning
4.1 Parameter setting
Status/fault messages Change parameters
smd004
Note
If the password function is enabled, the password must be entered into C00 to
access the parameters. C00 will not appear unless the password function is enabled.
See C94.
