ENGLISH
15
Commissioning
Code Possible Settings
IMPORTANT
No. Name Lenze Selection
Acceleration time 2 5.0 0.0 {s} 999 • Activated using CE1...CE3
• c01 = frequency change 0 Hz...C11
• c03 = frequency change C11...0 Hz
• For S-ramp accel/decel, adjust c82
Deceleration time 2 5.0 0.0 {s} 999
Holding time -
automatic DC
injection brake
(Auto-DCB)
0.0 0.0 {s} 999
0.0 = not active
999 = continuous brake
• Automatic motor braking below 0.1 Hz
by means of motor DC current for the
entire holding time (afterwards: U, V,
W inhibited)
• Conrm motor suitability for use with
DC braking
I
2
t switch-off (thermal
motor monitoring)
100 30 {%} 100
100% = smd rated output current
• Triggers 0 fault when motor current
exceeds for too long
= motor current rating x 100
smd output rating
Example: if motor = 6.4amps and smd =
7.0amps, then = 91%
WARNING!
Maximum setting is rated motor current (see nameplate). Does not provide full
motor protection!
Actual PI setpoint c86 c87 Display
Frequency setpoint
via keys
0.0 0.0 {Hz} 500 Only active if C01 = 1
Start condition
(with mains on)
1 0 Start after LOW-HIGH change at
terminal 28
See also c70
1 Auto start if terminal 28 = HIGH
WARNING!
Automatic starting/restarting may cause damage to equipment and/or injury to
personnel! Automatic starting/restarting should only be used on equipment that is
inaccessible to personnel.
Mode selection
for c61
0
0 Monitoring only
c60 = 1 allows the keys
to adjust
speed setpoint (c40) while monitoring
c61
1 Monitoring and editing
Present status/error status/error message • Display
• Refer to Section 5 for explanation of
status and error messages
Last error error message
Last error but one
7
Conguration TRIP
reset (error reset)
0 0 TRIP reset after LOW-HIGH
change at terminal 28, mains
switching, or after LOW-HIGH
change at digital input “TRIP reset”
1 Auto-TRIP reset • Auto-TRIP reset after the time set in
c71
• More than 8 errors in 10 minutes will
trigger fault
WARNING!
Automatic starting/restarting may cause damage to equipment and/or injury to
personnel! Automatic starting/restarting should only be used on equipment that is
inaccessible to personnel.
