Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019 103
Parameter reference
Parameters of the Communication Unit
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13871
C13872
C13873
Parameter | Name:
C13871 | CIP Connections Type
Data type: UNSIGNED_16
Index: 10704 = 0x29D0
Display of the current CIP connection types
• "Listen Only" connections are not displayed.
Selection list (read only)
0 Nonexistent
1 Exclusive Owner
2 Input Only
3 Listen Only
4 Explicit Connection
Subcodes Info
C13871/1 Type of CIP connection 1
... ...
C13871/8 Type of CIP connection 8
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13872 | CIP Connection Triggers
Data type: UNSIGNED_16
Index: 10703 = 0x29CF
Display of the current CIP connection class
Selection list (read only)
0 Nonexistent
1 Class 1, Cyclic, Client
163 Class 3, App. Obj., Server
Subcodes Info
C13872/1 Trigger of CIP connection 1
... ...
C13872/8 Trigger of CIP connection 8
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13873 | CIP Connections RPI
Data type: UNSIGNED_32
Index: 10702 = 0x29CE
Display of the RPI times (Requested Package Interval) currently used for the CIP connections ("Originator to Target"
time)
Display range (min. value | unit | max. value)
0 ms 4294967295
Subcodes Info
C13873/1 RPI of CIP connection 1
... ...
C13873/8 RPI of CIP connection 8
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
