Installation
Mechanical installation
22
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.1 Mechanical installation
[5-1] Mechanical installation of the 8400 motec components
Mounting instructions for the Inverter Drive 8400 motec
Here you will find detailed information on the installation.
0.37 ... 3.0 kW 4.0 ... 7.5 kW
E84DG023a
E84DG023b
Legend for fig. [5-1]
1Drive Unit
2 Communication unit
3 Wiring Unit
A Cover of the Drive Unit
EDK84DG... Mounting instructions of the Drive Unit, Communication Unit, Wiring Unit
