Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019 47
I/O data transfer (implicit messages)
Configuring I/O data
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
• In the assembly input object instances 70 ... 73 (0x46 ... 0x49), this data is not used due to
profile conformity reasons.
• The I/O data configuration is application-specifically predefined in the device description files
and can be adapted, if necessary.
I/O configuration in the »Engineer«
( 53)
