Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019 97
Parameter reference
Parameters of the Communication Unit
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13020
C13021
C13022
Parameter | Name:
C13020 | Multicast Config Num Mcast
Data type: UNSIGNED_8
Index: 11555 = 0x2D23
Used to set how many multicast IP addresses will be assigned.
(Instance attribute 9 (Num Mcast) in the TCP/IP Interface Object (245 / 0xF5)
( 126))
Setting range (min. value | unit | max. value) Lenze setting
181
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13021 | Quality of Service (VLAN-Tagging)
Data type: UNSIGNED_8
Index: 11554 = 0x2D22
Used to set whether QoS tags will be used for the prioritisation of the data packets to be transferred.
(Instance attribute 1 (802.1Q Tag Enable) in the Quality of Service (QoS) Object (72 / 0x48)
( 124))
Selection list (Lenze setting printed in bold)
0 802.1Q Tag Disable
1 802.1Q Tag Enable
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13022 | Quality of Service (DSCP)
Data type: UNSIGNED_8
Index: 11553 = 0x2D21
Setting for the prioritisation of the data packets to be transferred using Differentiated Services Codepoints (DSCP)
Setting range (min. value | unit | max. value)
063
Subcodes Lenze setting Info
C13022/1 59 Reserved
C13022/2 47 Reserved
C13022/3 55 Reserved
C13022/4 47 QoS DSCP Scheduled
(Instance attribute 5 (DSCP Scheduled) in the Quality of
Service (QoS) Object (72 / 0x48) ( 124))
C13022/5 43 QoS DSCP High Prio
(Instance attribute 6 (DSCP High Prio) in the Quality of
Service (QoS) Object (72 / 0x48) ( 124))
C13022/6 31 Reserved
C13022/7 27 QoS DSCP Explicit Msg
(Instance attribute 8 (DSCP Explicit Msg.) in the Quality
of Service (QoS) Object (72 / 0x48) ( 124))
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
