Installation
4-2 821XKlimaBA0399
Possible mounting positions for types 8211 to 8214
- In vertical position at the back of the control cabinet,
terminals point to the front:
- With attached fixing rails.
- With special fixing unit on one or two DIN rails.
- Turned by 90 (flat assembly on the backside of the control
cabinet):
- Insert the attached fixing rail into the guides at the heat
sink.
- Horizontally with an additional fan.
- On a pivoting frame for assembly depths < 198 mm:
- Therefore easy handling and installation of the front
interfaces possible.
Possible mounting positions for types 8215 to 8218
- In vertical position at the back of the control cabinet,
terminals point to the front:
- With attached fixing rails.
- Thermally separated with external heat sink
(”push-through technology”).
