Lenze g500-B - Final Configuration

Final conguraon
Check
Connecon dimensions Output sha
Output ange/foot
Mounng posion Geared motor
Terminal box
Driven sha/output ange
Select product extensions and accessories Torque support
Sha cover
Connectors
Brake
NFC adapter
QUICKON connector
M15 connector
More informaon about the nal conguraon:
4The modular system ^ 12
4Product extensions ^ 91
4Accessories ^ 108
Parameters that can be preset by Lenze
The parameters marked with "order-dependent" in the standard seng can be
preset order-related by Lenze.
Standard sengs
Parameter Value Comment
Name Delivery Seng range
Parameter set name --- [text] File name of the parameter set without le
extension *.lsm
Output speed 1 depending on the order [-2600/i ... -500/i] rpm
[0] rpm
[500/i ... 2600/i] rpm
CCW rotaon: < 0 rpm
STOP: 0 rpm
CW rotaon: > 0 rpm
Lenze Smart Motor with gearbox: The rao i is
taken into account when calculang the output
speed.
Output speed 2
Output speed 3
Output speed 4
Output speed 5
Acceleraon me [0.0 ... 20.0] s
n
max
t
Acceleraon me t
1
of the ramp generator from
0 rpm to n
max
[2600/i] rpm
Deceleraon me Deceleraon me t
2
of the ramp generator from
n
max
[2600/i] rpm to 0 rpm
Energy-saving funcon [O] Opmized for:
•
High dynamic performance
•
Maximum starng torque and torque
•
High speed accuracy
[On] Reduced energy absorpon in paral load
operaonal range.
Approx. 50 % of the maximum starng torque is
available.
Informaon on project planning
Final conguraon
26
