Lenze g500-B - Lubricants

Lubricants
The following gearboxes are lubricated for life:
•
g500-B45
•
g500-B110
•
g500-B240
Recommended lubricants:
Lubricant CLP 220 CLP 460 CLP HC 220 CLP HC 320
Ambient temperature 0 … +40 °C -30 … +40 °C -20 … +50 °C
Specicaon Mineral oil with EP addives Synthec oil (polyalfaolens basis)
Changing interval
Operang hours 16000 25000
Not later than aer 3 years 4 years
At an oil temperature of 70 °C 70 °C
FUCHS Renolin
CLP 220
Renolin
CLP 460
Renolin Unisyn
XT 220
Renolin Unisyn
XT 320
KLÜBER Klüberoil
GEM 1-220 N
Klüberoil
GEM 1-460 N
Klübersynth
GEM 4-220 N
Klübersynth
GEM 4-320 N
SHELL Shell Omala
S2 GX 220
Shell Omala
S2 GX 460
Shell Omala
S4 GXV 220
Shell Omala
S4 GXV 320
Lubricant CLP HC 46
USDA H1
CLP PG 100
USDA H1
CLP HC 220
USDA H1
CLP PG 460
USDA H1
Ambient temperature -30 … +10 °C -20 … +40 °C
Specicaon Synthec oil
(polyalfaolens basis)
Synthec oil (polyglycol
basis)
Synthec oil
(polyalfaolens basis)
Synthec oil (polyglycol
basis)
Changing interval
Operang hours 16000
Not later than aer 3 years
At an oil temperature of 70 °C
FUCHS Cassida Fluid GL 220 Cassida Fluid WG 460
KLÜBER Klüberoil
Summit HYSYN FG-46
Klübersynth
UH1 6-100
Klüberoil
4 UH1-220 N
Klübersynth
UH1 6-460
Castrol Opleb
GT 1800/460
Lubricant amounts for stocking
All lubricant amounts are reference values for a change of lubricant. They serve stocking
purposes, for example.
The exact values can be found on the nameplate.
Mounng posion M1 (A) M2 (D) M3 (B) M4 (C) M5 (E) M6 (F) M1-M6
(A-F)
M1, M5, M6
(AEF)
Gearboxes
g500-B45 l 0.4 0.4 0.4 0.4 0.4 0.4 0.4 -
g500-B110 l .3 0.6 0.7 .9 0.5 0.4 - 0.5
g500-B240 l .9 1.2 1.3 1.8 1.4 1.0 - 1.4
g500-B450 l .9 1.6 1.9 2.3 1.8 1.7 - 1.8
g500-B600 l 1.4 2.3 2.7 3.2 2.6 2.6 - -
g500-B820 l 1.9 2.8 3.4 4.2 3.2 2.7 - -
g500-B1500 l 3.8 5.7 6.4 8.4 5.9 3.9 - -
g500-B2700 l 6.0 9.0 10.0 12.7 8.5 9.5 - -
g500-B4300 l 9.5 11.5 16.5 21.0 14.0 16.0 - -
Pre-stage l 0.4
4Gearbox with pre-stage ^ 89
