Lenze g500-B - Weights; Basic Weights; Additional Weights

Weights
Basic weights
The basic weights are listed in the selecon tables.
Weights with lubricant for mounng posion M1, all data approximate values.
The exact values can be found in the delivery documents
4Selecon tables ^ 53
Observe 4Addional weights ^ 90!
Addional weights
Gearboxes
Gearboxes g500-B45 g500-B110 g500-B240 g500-B450
Solid sha m kg 0.4 0.5 1.4 1.0
Shrink disc m kg 0.2 0.2 0.7 0.6
Flange m kg 0.3 0.4 0.7 0.9
Torque plate
Threaded pitch circle m kg 0.3 0.5 1.3 2.5
Housing foot m kg - - 2.4 1.1
Housing foot, GKS compable m kg - - - -
Sha cover
Shrink disc cover m kg 0.1 0.1 0.1 0.1
Hollow sha cover, hoseproof m kg 0.1 0.1 0.1 0.2
Gearboxes g500-B600 g500-B820 g500-B1500 g500-B2700 g500-B4300
Solid sha m kg 1.5 1.9 3.7 6.0 15.5
Shrink disc m kg 0.6 1.2 1.7 2.3 4.3
Flange m kg 6.1 6.1 11.5 15.0 29.0
Torque plate
Threaded pitch circle m kg 2.5 2.5 4.5 - -
Housing foot m kg 2.8 3.0 4.3 10 13
Housing foot, GKS compable m kg 5,0 5,0 8.2 16.5 30.5
Sha cover
Shrink disc cover m kg 0.1 0.1 0.2 0.3 0.4
Hollow sha cover, hoseproof m kg 0.3 0.3 0.6 0.6 0.8
Motors
Motor MSEMAXX063-42 MSEMAXX080-32
Brake
Spring pressure - holding brake m kg 0,9 1.5
Manual release lever m kg 0.03 0.04
Brake resistors
Internal m kg 0.05 0.05
External m kg 0.17 0.17
Technical data
Weights
Basic weights
90
