g500-B820 ... B1500
Gearboxes Dimensions
a
4
a
7
a
8
a
9
b
4
d D k
6
mm mm mm mm mm mm mm mm
g500-B820 38.0 28.0 200 31.5 40,0 20,0 50.0 20.5
g500-B1500 44.0 32.0 250 36.0 46.0 25.0 65.0 24.0
Product extensions
Torque plates
120
