Lenze G7 Series User Manual

7.5 kW
Inverter operaon Geared motor Number of
stages
M
2
n
2
c M
2, max
n
2, th
J i g500- m850 z m
Nm rpm Nm rpm kgcm² kg
113 605 2.2 312 431 128.522 4.958 B820 190M30 3 64
116 592 2.6 376 438 123.731 5.067 B600 190M30 3 59
155 441 2.0 391 359 123.711 6.800 B820 190M30 3 64
157 437 4.2 783 308 138.952 6.866 B1500 190M30 3 94
158 432 2.0 398 353 121.163 6.949 B600 190M30 3 59
174 394 1.9 424 271 126.472 7.618 B820 190M30 3 64
174 394 2.1 462 278 122.790 7.617 B600 190M30 3 59
194 352 1.9 459 238 126.071 8.517 B820 190M30 3 64
209 328 4.0 1044 239 166.653 9.156 B4300 190M30 3 198
217 315 3.7 1006 248 130.064 9.516 B1500 190M30 3 94
217 315 1.8 496 294 120.761 9.520 B820 190M30 3 64
238 287 1.8 528 218 122.620 10.447 B820 190M30 3 64
245 279 1.8 541 181 122.118 10.741 B600 190M30 3 59
249 275 4.3 1243 194 135.614 10.902 B1500 190M30 3 94
266 257 1.7 569 191 122.407 11.680 B820 190M30 3 64
273 250 4.2 1366 176 135.132 11.985 B1500 190M30 3 94
277 247 1.6 544 241 119.520 12.143 B820 190M30 3 64
299 229 3.0 1118 203 124.661 13.118 B1500 190M30 3 94
305 224 1.4 553 177 119.506 13.369 B600 190M30 3 59
305 224 1.6 619 188 120.701 13.370 B820 190M30 3 64
333 205 1.6 653 176 120.204 14.626 B820 190M30 3 64
336 204 1.4 600 137 120.306 14.730 B600 190M30 3 59
344 199 3.5 1500 154 128.326 15.111 B1500 190M30 3 94
373 184 1.5 708 155 120.096 16.352 B820 190M30 3 64
379 181 3.1 1500 137 128.075 16.611 B1500 190M30 3 94
386 177 4.0 1928 130 156.664 16.913 B4300 190M30 3 198
421 162 4.0 2107 119 155.539 18.486 B4300 190M30 3 198
424 161 2.8 1500 135 125.197 18.598 B1500 190M30 3 94
425 161 1.4 747 149 119.178 18.655 B820 190M30 3 64
430 159 1.1 600 110 119.288 18.851 B600 190M30 3 59
445 154 4.0 2227 112 136.748 19.542 B2700 190M30 3 136
466 147 2.6 1500 120 125.031 20.444 B1500 190M30 3 94
470 146 1.0 600 101 119.023 20.622 B600 190M30 3 59
475 144 1.4 820 132 119.111 20.857 B820 190M30 3 64
480 142 3.7 2213 112 147.359 21.065 B4300 190M30 3 198
508 135 3.7 2339 106 132.887 22.269 B2700 190M30 3 136
521 131 1.3 820 131 118.597 22.853 B820 190M30 3 64
522 131 2.3 1500 110 123.615 22.898 B1500 190M30 3 94
529 129 3.2 2138 112 139.767 23.206 B4300 190M30 3 198
547 125 2.2 1500 75.0 127.192 23.973 B1500 190M30 3 94
558 123 3.7 2569 96.3 132.613 24.456 B2700 190M30 3 136
578 118 3.2 2337 102 139.170 25.365 B4300 190M30 3 198
582 117 1.1 820 114 118.553 25.550 B820 190M30 3 64
600 114 1.1 820 57.5 120.077 26.324 B820 190M30 3 64
601 114 2.0 1500 66.9 127.093 26.353 B1500 190M30 3 94
611 112 3.2 2471 96.6 129.188 26.814 B2700 190M30 3 136
666 103 1.8 1500 92.2 121.294 29.206 B1500 190M30 3 94
671 102 3.2 2700 87.9 128.999 29.447 B2700 190M30 3 136
709 96.5 2.8 2466 88.0 132.889 31.097 B4300 190M30 3 198
742 92.2 1.6 1500 86.6 120.263 32.547 B1500 190M30 3 94
749 91.3 2.8 2607 83.2 126.248 32.873 B2700 190M30 3 136
Technical data
Selecon tables
Inverter mains connecon 400 V, Self-venlated motors
85
