Lenze G7 Series User Manual

Inverter operaon Geared motor Number of
stages
M
2
n
2
c M
2, max
n
2, th
J i g500- m850 z m
Nm rpm Nm rpm kgcm² kg
816 83.9 1.5 1500 75.2 120.210 35.778 B1500 190M30 3 94
823 83.1 2.6 2700 74.9 126.122 36.102 B2700 190M30 3 136
833 82.1 1.4 1500 46.4 123.890 36.526 B1500 190M30 3 94
879 77.8 2.2 2384 77.8 126.371 38.546 B4300 190M30 3 198
932 73.4 1.5 1500 47.2 122.303 40.895 B1500 190M30 3 94
975 70.2 4.0 4300 51.2 133.931 42.760 B4300 190M30 3 198
975 70.1 2.5 2700 46.1 131.139 42.772 B2700 190M30 3 136
1025 66.7 1.3 1500 40.8 122.269 44.955 B1500 190M30 3 94
1062 64.4 1.3 1500 64.4 119.138 46.568 B1500 190M30 3 94
1065 64.2 3.6 4300 46.0 133.755 46.737 B4300 190M30 3 198
1071 63.9 2.3 2700 41.0 131.065 46.973 B2700 190M30 3 136
1115 61.3 2.2 2700 61.3 122.468 48.912 B2700 190M30 3 136
1184 57.8 1.1 1500 57.8 118.485 51.920 B1500 190M30 3 94
1214 56.3 3.2 4300 42.9 130.583 53.258 B4300 190M30 3 198
1233 55.5 2.0 2700 55.5 118.113 54.082 B2700 190M30 3 136
1301 52.6 1.0 1500 52.6 118.464 57.074 B1500 190M30 3 94
1332 51.4 1.0 1500 34.3 119.957 58.422 B1500 190M30 3 94
1337 51.1 2.9 4300 43.2 127.692 58.671 B4300 190M30 3 198
1354 50.5 1.8 2700 50.5 118.113 59.393 B2700 190M30 3 136
1462 46.8 2.7 4300 38.7 127.598 64.127 B4300 190M30 3 198
1469 46.5 1.7 2700 32.3 126.170 64.452 B2700 190M30 3 136
1640 41.7 1.5 2700 30.4 124.266 71.951 B2700 190M30 3 136
1640 41.7 2.4 4300 36.8 125.253 71.930 B4300 190M30 3 198
1752 39.0 1.4 2700 39.0 119.609 76.862 B2700 190M30 3 136
1792 38.2 2.2 4300 33.0 125.191 78.619 B4300 190M30 3 198
1936 35.3 1.3 2700 35.3 118.923 84.940 B2700 190M30 3 136
2127 32.2 1.1 2700 32.2 118.904 93.283 B2700 190M30 3 136
2222 30.8 1.1 2700 24.1 121.457 97.481 B2700 190M30 3 136
2222 30.8 1.8 4300 30.0 121.994 97.453 B4300 190M30 3 198
2428 28.2 1.6 4300 26.2 121.960 106.517 B4300 190M30 3 198
2441 28.0 1.0 2700 21.1 121.442 107.056 B2700 190M30 3 136
2698 25.4 1.6 4300 25.4 118.113 118.336 B4300 190M30 3 198
2698 25.3 1.0 2700 22.1 118.113 118.370 B2700 190M30 3 136
2949 23.2 1.5 4300 23.2 118.113 129.342 B4300 190M30 3 198
3491 19.6 1.2 4300 19.6 119.417 153.141 B4300 190M30 3 198
3816 17.9 1.1 4300 17.9 119.403 167.383 B4300 190M30 3 198
4237 16.1 1.0 4300 16.1 118.773 185.857 B4300 190M30 3 198
Technical data
Selecon tables
Inverter mains connecon 400 V, Self-venlated motors
86
