Lenze G7 Series User Manual

9.2 kW
Inverter operaon Geared motor Number of
stages
M
2
n
2
c M
2, max
n
2, th
J i g500- m850 z m
Nm rpm Nm rpm kgcm² kg
165 508 1.6 312 371 204.522 4.958 B820 190L25 3 76
168 497 1.9 376 399 199.731 5.067 B600 190L25 3 71
226 371 1.5 391 302 199.711 6.800 B820 190L25 3 76
228 367 3.1 837 286 214.952 6.866 B1500 190L25 3 107
231 363 1.5 398 295 197.163 6.949 B600 190L25 3 71
232 361 3.7 1028 272 274.324 6.976 B4300 190L25 3 210
253 331 1.4 424 226 202.472 7.618 B820 190L25 3 76
253 331 1.5 462 237 198.790 7.617 B600 190L25 3 71
283 296 1.4 459 199 202.071 8.517 B820 190L25 3 76
292 287 3.7 1296 216 226.939 8.793 B2700 190L25 3 148
304 275 3.1 1138 227 242.653 9.156 B4300 190L25 3 210
316 265 2.7 1006 231 206.064 9.516 B1500 190L25 3 107
316 265 1.3 496 248 196.761 9.520 B820 190L25 3 76
347 241 1.3 528 184 198.620 10.447 B820 190L25 3 76
357 235 1.3 541 152 198.118 10.741 B600 190L25 3 71
362 231 3.1 1330 180 211.614 10.902 B1500 190L25 3 107
388 216 1.2 569 162 198.407 11.680 B820 190L25 3 76
398 210 3.1 1461 164 211.132 11.985 B1500 190L25 3 107
404 208 1.1 544 202 195.520 12.143 B820 190L25 3 76
428 196 3.7 1900 147 257.116 12.885 B4300 190L25 3 210
436 192 2.2 1118 187 200.661 13.118 B1500 190L25 3 107
444 189 1.1 553 151 195.506 13.369 B600 190L25 3 71
444 189 1.2 619 159 196.701 13.370 B820 190L25 3 76
468 179 3.7 2076 135 255.177 14.084 B4300 190L25 3 210
486 172 1.1 653 150 196.204 14.626 B820 190L25 3 76
490 171 1.0 600 118 196.306 14.730 B600 190L25 3 71
495 169 3.7 2195 127 222.802 14.888 B2700 190L25 3 148
502 167 2.5 1500 143 204.326 15.111 B1500 190L25 3 107
544 154 1.1 708 132 196.096 16.352 B820 190L25 3 76
544 154 3.7 2410 116 222.188 16.351 B2700 190L25 3 148
552 152 2.3 1500 127 204.075 16.611 B1500 190L25 3 107
562 149 3.1 2101 123 232.664 16.913 B4300 190L25 3 210
615 136 3.1 2297 113 231.539 18.486 B4300 190L25 3 210
618 136 2.0 1500 126 201.197 18.598 B1500 190L25 3 107
620 135 1.0 747 131 195.178 18.655 B820 190L25 3 76
650 129 3.1 2428 106 212.748 19.542 B2700 190L25 3 148
680 123 1.9 1500 109 201.031 20.444 B1500 190L25 3 107
700 120 2.9 2395 106 223.359 21.065 B4300 190L25 3 210
740 113 2.9 2532 100 208.887 22.269 B2700 190L25 3 148
761 110 1.7 1500 95.9 199.615 22.898 B1500 190L25 3 107
771 109 2.5 2312 106 215.767 23.206 B4300 190L25 3 210
797 105 1.6 1500 64.0 203.192 23.973 B1500 190L25 3 107
813 103 2.8 2700 90.7 208.613 24.456 B2700 190L25 3 148
843 99.4 2.5 2527 96.5 215.170 25.365 B4300 190L25 3 210
876 95.6 1.4 1500 55.1 203.093 26.353 B1500 190L25 3 107
891 94.0 2.5 2672 91.3 205.188 26.814 B2700 190L25 3 148
971 86.3 1.3 1500 77.3 197.294 29.206 B1500 190L25 3 107
979 85.6 2.3 2700 81.7 204.999 29.447 B2700 190L25 3 148
1034 81.0 2.2 2661 78.7 208.889 31.097 B4300 190L25 3 210
1082 77.4 1.2 1500 74.6 196.263 32.547 B1500 190L25 3 107
1093 76.7 2.1 2700 74.5 202.248 32.873 B2700 190L25 3 148
Technical data
Selecon tables
Inverter mains connecon 400 V, Self-venlated motors
87
