The "Enable inverter" 0x2631:001 (P400.01) funcon must be set to TRUE to
start the motor. Either via digital input or by default seng "Constant TRUE [1]".
If the funcon is set to FALSE, the inverter is disabled. The motor becomes tor-
queless (coasts).
In case of an acvated keypad or network control, the "Run" 0x2631:002
(P400.02)funcon must be addionally set to TRUE to start the motor. Either via
digital input or by the "Constant TRUE [1]" seng.
Notes:
•
In case of an acvated keypad or network control, the following funcons are sll acve:
•
0x2631:001 (P400.01): Enable inverter
•
0x2631:002 (P400.02): Run
•
0x2631:003 (P400.03): Acvate quick stop
•
0x2631:004 (P400.04): Reset fault
•
0x2631:005 (P400.05): Acvate DC braking
•
0x2631:010 (P400.10): Jog foward (CW)
•
0x2631:011 (P400.11): Jog reverse (CCW)
•
0x2631:012 (P400.12): Acvate keypad control
•
0x2631:037 (P400.37): Acvate network control
•
0x2631:043 (P400.43): Acvate fault 1
•
0x2631:044 (P400.44): Acvate fault 2
•
0x2631:054 (P400.54): Posion counter reset
•
In case of an acvated network control, the following addional funcons are sll acve:
•
0x2631:013 (P400.13): Reverse rotaonal direcon
•
The funcons for setpoint change-over.4Setpoint change-over ^ 365
All other funcons congurable via 0x2631:xx (P400.xx) are deacvated in case of keypad
or network control.
Diagnosc parameters:
•
0x282A:001 (P126.01): Cause of disable
•
0x282A:002 (P126.02): Cause of quick stop
•
0x282A:003 (P126.03): Cause of stop
•
0x282B:001 (P125.01): Acve control source
For descripon of the basic funcons for controlling the motor, see chapter "Start / stop
motor". ^ 350
Parameter Name / value range / [default seng] Info
0x2631:012
(P400.12)
Funcon list: Acvate keypad control
(Funcon list: Keypad control)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate keypad control" funcon.
Trigger = TRUE: acvate keypad as control source.
Trigger = FALSE: no acon / deacvate keypad as control source again.
0 Not connected
0x2631:037
(P400.37)
Funcon list: Acvate network control
(Funcon list: Network control)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate network control" funcon.
Trigger = TRUE: Acvate network control.
Trigger = FALSE: No acon / deacvate network control again.
0 Not connected
114 Network control acve (from version 02.00) TRUE if the network control is requested via bit 5 of the AC drive control
word 0x400B:001 (P592.01). Otherwise FALSE.
Notes:
•
Set this selecon if the network control is to be acvated via bit 5 of
the AC drive control word.
•
The AC drive control word can be used with any communicaon pro-
tocol.
4AC Drive Prole ^ 193
