Lenze i55 Series - Page 91

Display code Short designaon Default seng Seng range Address Category
└ P351.03 Magn. current 0.96 A * 0.00 ... 500.00 A 0x2C02:003 MCTRL
└ P351.04 Slip frequency x.x Hz - (Read only) 0x2C02:004 general
P352.xx PSM motor par.
└ P352.01 BEMF constant 41.8 V/1000rpm 0.0 ... 100000.0 V/1000rpm 0x2C03:001 MCTRL
P353.xx Overcurr. monit.
└ P353.01 Threshold 6.8 A * 0.0 ... 1000.0 A 0x2D46:001 general
└ P353.02 Response Fault [3] Selecon list 0x2D46:002 general
P354.00 Voltage reserve 5 % 1 ... 20 % 0x29E4 general
P400.xx Funcon list
└ P400.01 Enable inverter TRUE [1] Selecon list 0x2631:001 general
└ P400.02 Run Digital input 1 [11] Selecon list 0x2631:002 general
└ P400.03 Quick stop Not connected [0] Selecon list 0x2631:003 general
└ P400.04 Reset fault Digital input 2 [12] Selecon list 0x2631:004 general
└ P400.05 DC braking Not connected [0] Selecon list 0x2631:005 general
└ P400.06 Start forward Not connected [0] Selecon list 0x2631:006 general
└ P400.07 Start reverse Not connected [0] Selecon list 0x2631:007 general
└ P400.08 Run forward Not connected [0] Selecon list 0x2631:008 general
└ P400.09 Run reverse Not connected [0] Selecon list 0x2631:009 general
└ P400.10 Jog foward Not connected [0] Selecon list 0x2631:010 general
└ P400.11 Jog reverse Not connected [0] Selecon list 0x2631:011 general
└ P400.12 Keypad control Not connected [0] Selecon list 0x2631:012 general
└ P400.13 Reverse rot.dir. Digital input 3 [13] Selecon list 0x2631:013 general
└ P400.14 Setp: AI1 Not connected [0] Selecon list 0x2631:014 general
└ P400.15 Setp: AI2 Not connected [0] Selecon list 0x2631:015 general
└ P400.16 Setp: Keypad Not connected [0] Selecon list 0x2631:016 general
└ P400.17 Setp: Network Not connected [0] Selecon list 0x2631:017 general
└ P400.18 Setp: Preset b0 Digital input 4 [14] Selecon list 0x2631:018 general
└ P400.19 Setp: Preset b1 Digital input 5 [15] Selecon list 0x2631:019 general
└ P400.20 Setp: Preset b2 Not connected [0] Selecon list 0x2631:020 general
└ P400.21 Setp: Preset b3 Not connected [0] Selecon list 0x2631:021 general
└ P400.22 Setp: HTL input Not connected [0] Selecon list 0x2631:022 general
└ P400.23 MOP up Not connected [0] Selecon list 0x2631:023 general
└ P400.24 MOP down Not connected [0] Selecon list 0x2631:024 general
└ P400.25 Setp: MOP Not connected [0] Selecon list 0x2631:025 general
└ P400.26 Setp: Segment b0 Not connected [0] Selecon list 0x2631:026 general
└ P400.27 Setp: Segment b1 Not connected [0] Selecon list 0x2631:027 general
└ P400.28 Setp: Segment b2 Not connected [0] Selecon list 0x2631:028 general
└ P400.29 Setp: Segment b3 Not connected [0] Selecon list 0x2631:029 general
└ P400.30 Seq: Run/abort Not connected [0] Selecon list 0x2631:030 general
└ P400.31 Seq: Start Not connected [0] Selecon list 0x2631:031 general
└ P400.32 Seq: Next step Not connected [0] Selecon list 0x2631:032 general
└ P400.33 Seq: Pause Not connected [0] Selecon list 0x2631:033 general
└ P400.34 Seq: Suspense Not connected [0] Selecon list 0x2631:034 general
└ P400.35 Seq: Stop Not connected [0] Selecon list 0x2631:035 general
└ P400.36 Seq: Abort Not connected [0] Selecon list 0x2631:036 general
└ P400.37 Network control Not connected [0] Selecon list 0x2631:037 general
└ P400.39 Acv. ramp 2 Not connected [0] Selecon list 0x2631:039 general
└ P400.40 Load param.set Not connected [0] Selecon list 0x2631:040 general
└ P400.41 Sel. paramset b0 Not connected [0] Selecon list 0x2631:041 general
└ P400.42 Sel. paramset b1 Not connected [0] Selecon list 0x2631:042 general
└ P400.43 Fault 1 Not connected [0] Selecon list 0x2631:043 general
└ P400.44 Fault 2 Not connected [0] Selecon list 0x2631:044 general
└ P400.45 PID o Not connected [0] Selecon list 0x2631:045 general
└ P400.46 PID output=0 Not connected [0] Selecon list 0x2631:046 general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
91
