Lenze i55 Series - Page 92

Display code Short designaon Default seng Seng range Address Category
└ P400.47 PID-I inhibited Not connected [0] Selecon list 0x2631:047 general
└ P400.48 PID-Inf ramp on TRUE [1] Selecon list 0x2631:048 general
└ P400.49 Release brake Not connected [0] Selecon list 0x2631:049 general
└ P400.50 Seq: Select. b0 Not connected [0] Selecon list 0x2631:050 general
└ P400.51 Seq: Select. b1 Not connected [0] Selecon list 0x2631:051 general
└ P400.52 Seq: Select. b2 Not connected [0] Selecon list 0x2631:052 general
└ P400.53 Seq: Select. b3 Not connected [0] Selecon list 0x2631:053 general
└ P400.54 PosCounter reset Not connected [0] Selecon list 0x2631:054 general
└ P400.55 Acv. UPS oper. Not connected [0] Selecon list 0x2631:055 general
P410.xx DI sengs
└ P410.01 Asseron level HIGH acve [1] Selecon list 0x2630:001 general
└ P410.02 Input funcon Digital Input [0] Selecon list 0x2630:002 general
P411.xx DI inversion
└ P411.01 DI1 inversion Not inverted [0] Selecon list 0x2632:001 general
└ P411.02 DI2 inversion Not inverted [0] Selecon list 0x2632:002 general
└ P411.03 DI3 inversion Not inverted [0] Selecon list 0x2632:003 general
└ P411.04 DI4 inversion Not inverted [0] Selecon list 0x2632:004 general
└ P411.05 DI5 inversion Not inverted [0] Selecon list 0x2632:005 general
└ P411.06 DI6 inversion Not inverted [0] Selecon list 0x2632:006 Appl. I/O
└ P411.07 DI7 inversion Not inverted [0] Selecon list 0x2632:007 Appl. I/O
P412.00 Freq. threshold 0.0 Hz 0.0 ... 599.0 Hz 0x4005 general
P413.00 MOP startmode Last value [0] Selecon list 0x4003 general
P414.xx MOP start value
└ P414.01 Frequency 0.0 Hz 0.0 ... 599.0 Hz 0x4004:001 general
└ P414.02 PID value 0.00 PID unit -300.00 ... 300.00 PID unit 0x4004:002 general
└ P414.03 Torque 0.0 % 0.0 ... 1000.0 % 0x4004:003 general
P415.xx HTL inp. seng
└ P415.01 Min.frequency 0.0 Hz -100000.0 ... 100000.0 Hz 0x2640:001 general
└ P415.02 Max. frequency 0.0 Hz -100000.0 ... 100000.0 Hz 0x2640:002 general
└ P415.03 Min.motor.freq 0.0 Hz -1000.0 ... 1000.0 Hz 0x2640:003 general
└ P415.04 Max.motor.freq Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
-1000.0 ... 1000.0 Hz 0x2640:004 general
└ P415.05 Min.PID setpoint 0.00 PID unit -300.00 ... 300.00 PID unit 0x2640:005 general
└ P415.06 Max.PID setpoint 100.00 PID unit -300.00 ... 300.00 PID unit 0x2640:006 general
└ P415.07 Min.torque setp. 0.0 % -400.0 ... 400.0 % 0x2640:007 general
└ P415.08 Max.torque setp 100.0 % -400.0 ... 400.0 % 0x2640:008 general
└ P415.09 Filter me 10 ms 0 ... 10000 ms 0x2640:009 general
P416.xx HTL inp. monit.
└ P416.01 Min.freq.thresh. 0.0 Hz -214748364.8 ...
214748364.7 Hz
0x2641:001 general
└ P416.02 Min.delay thres. 5.0 s 0.0 ... 300.0 s 0x2641:002 general
└ P416.03 Max.freq.thresh. 0.0 Hz -214748364.8 ...
214748364.7 Hz
0x2641:003 general
└ P416.04 Max.delay thres. 5.0 s 0.0 ... 300.0 s 0x2641:004 general
└ P416.05 Monit. condion < min. frequency [1] Selecon list 0x2641:005 general
└ P416.06 Error response No response [0] Selecon list 0x2641:006 general
P420.xx Dig.out.funcon
└ P420.01 Relay funcon Rdy for operat. [51] Selecon list 0x2634:001 general
└ P420.02 DO1 funcon Release brake [115] Selecon list 0x2634:002 general
└ P420.03 DO2 funcon Error [56] Selecon list 0x2634:003 Appl. I/O
└ P420.10 NetWordOUT1.00 Rdy for operat. [51] Selecon list 0x2634:010 general
└ P420.11 NetWordOUT1.01 Not connected [0] Selecon list 0x2634:011 general
└ P420.12 NetWordOUT1.02 Operat. enabled [52] Selecon list 0x2634:012 general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
92
