Lenze i55 Series

Display code Short designaon Default seng Seng range Address Category
└ P512.01 Port 1 Auto-Negoaon [0] Selecon list 0x23B4:001 Modbus TCP
└ P512.02 Port 2 Auto-Negoaon [0] Selecon list 0x23B4:002 Modbus TCP
P512.xx PROFIBUS Cong.
└ P512.01 Ext. diag. bit Delete [0] Selecon list 0x2344:001 PROFIBUS
P513.00 QualityOfService - - (Read only) 0x23A6 EtherNet/IP
P513.xx Act. port se.
└ P513.01 Port 1 - - (Read only) 0x23B5:001 Modbus TCP
└ P513.02 Port 2 - - (Read only) 0x23B5:002 Modbus TCP
P514.00 AddrConctDetec Enabled [1] Selecon list 0x23A7 EtherNet/IP
P514.xx MBTCP t-out mon
└ P514.01 Time-out me 2.0 s 0.0 ... 300.0 s 0x23B6:001 Modbus TCP
└ P514.02 Keep al t-out 2.0 s 0.0 ... 300.0 s 0x23B6:002 Modbus TCP
└ P514.05 Keep al register 0 0 ... 65535 0x23B6:005 Modbus TCP
P515.00 Time-out status - - (Read only) 0x2307 CANopen
P515.xx EtherCAT monit.
└ P515.01 WD elapsed Trouble [2] Selecon list 0x2859:001 EtherCAT
└ P515.03 Invalid cong Trouble [2] Selecon list 0x2859:003 EtherCAT
└ P515.04 Init. error Trouble [2] Selecon list 0x2859:004 EtherCAT
└ P515.05 Inval. proc.data Trouble [2] Selecon list 0x2859:005 EtherCAT
P515.xx EtherN/IP monit.
└ P515.01 WD elapsed Trouble [2] Selecon list 0x2859:001 EtherNet/IP
└ P515.03 Invalid cong Trouble [2] Selecon list 0x2859:003 EtherNet/IP
└ P515.04 Init. error Trouble [2] Selecon list 0x2859:004 EtherNet/IP
└ P515.05 Inval. proc.data Trouble [2] Selecon list 0x2859:005 EtherNet/IP
└ P515.06 Timeout ExplMsg Warning [1] Selecon list 0x2859:006 EtherNet/IP
└ P515.07 Timeout Comm. Warning [1] Selecon list 0x2859:007 EtherNet/IP
P515.xx Modbus monit.
└ P515.01 Resp. Time-out Fault [3] Selecon list 0x2858:001 Modbus RTU
└ P515.02 Time-out me 2.0 s 0.0 ... 300.0 s 0x2858:002 Modbus RTU
P515.xx MBTCP monitoring
└ P515.03 Cong error Trouble [2] Selecon list 0x2859:003 Modbus TCP
└ P515.04 Init error Trouble [2] Selecon list 0x2859:004 Modbus TCP
└ P515.07 React t-out netw Warning [1] Selecon list 0x2859:007 Modbus TCP
└ P515.08 React t-out mast Fault [3] Selecon list 0x2859:008 Modbus TCP
└ P515.09 Reac t-out kp-al Fault [3] Selecon list 0x2859:009 Modbus TCP
P515.xx PROFIBUS monit.
└ P515.01 WD elapsed Trouble [2] Selecon list 0x2859:001 PROFIBUS
└ P515.02 Data exch.exited No response [0] Selecon list 0x2859:002 PROFIBUS
└ P515.03 Invalid cong Trouble [2] Selecon list 0x2859:003 PROFIBUS
└ P515.04 Init. error Trouble [2] Selecon list 0x2859:004 PROFIBUS
└ P515.05 Inval. proc.data Trouble [2] Selecon list 0x2859:005 PROFIBUS
P515.xx PROFINET monit.
└ P515.01 WD elapsed Trouble [2] Selecon list 0x2859:001 PROFINET
└ P515.02 Data exch.exited No response [0] Selecon list 0x2859:002 PROFINET
└ P515.03 Invalid cong Trouble [2] Selecon list 0x2859:003 PROFINET
└ P515.04 Init. error Trouble [2] Selecon list 0x2859:004 PROFINET
└ P515.05 Inval. proc.data Trouble [2] Selecon list 0x2859:005 PROFINET
P516.00 CANopen status - - (Read only) 0x2308 CANopen
P516.00 EtherCAT status - - (Read only) 0x2368 EtherCAT
P516.00 CIP module stat. - - (Read only) 0x23A8 EtherNet/IP
P516.00 MBTCP modul. stat - - (Read only) 0x23B8 Modbus TCP
P516.xx PROFIBUS Status
└ P516.01 Bus status - - (Read only) 0x2348:001 PROFIBUS
└ P516.02 Watchdog status - - (Read only) 0x2348:002 PROFIBUS
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
97
