PTC-input X109
In the default setting, the motor temperature monitoring is active! By default, a wire jumper is
installed between the terminals T1 and T2. Before connecting a thermal sensor, remove the
wire jumper.
Connection type Screw terminal, pluggable
Max. cable cross-section mm² 1.5
Stripping length mm 6
Required tool
0.4 x 2.5
Application
T1
Connection of PTC or thermal contact
T2
Sensor types
PTC single sensor (DIN44081)
PTC triplet sensor (DIN44082)
Thermal contact
