Elektrische Installation
Anschlussplan
6
l
27
EDKRBS470R DE/EN/FR 10.0
6.3 Anschlussplan
Variante 1 (kurze Leitungen)
R
B
RB1 RB2
< 0.5 m
T1 T2
+
ERBG008
Verdrillte Leitungen
Variante 2 (lange Leitungen)
R
B
RB1 RB2
<5m
T1 T2
"
"
ERBG007
" HF−Schirmabschluss durch großflächige PE−Anbindung
Verdrillte Leitungen
