Installation électrique
Schéma de câblage
6
l
83
EDKRBS470R DE/EN/FR 10.0
6.3 Schéma de câblage
Variante 1 (câbles courts)
R
B
RB1 RB2
< 0.5 m
T1 T2
+
ERBG008
Câbles torsadés
Variante 2 (câbles longs)
R
B
RB1 RB2
<5m
T1 T2
"
"
ERBG007
" Connexion HF (collier de blindage) via connexion avec PE par surface
importante
Câbles torsadés
