Electrical installation
Connection plan
6
l
55
EDKRBS470R DE/EN/FR 10.0
6.3 Connection plan
Version 1 (short cables)
R
B
RB1 RB2
< 0.5 m
T1 T2
+
ERBG008
Twisted cables
Version 2 (long cables)
R
B
RB1 RB2
<5m
T1 T2
"
"
ERBG007
" HF−shield termination by extensive PE connection
Twisted cables
