Installation
Mechanical installation
5
Ò
42
EDSMDAG EN 2.0
EMDAG5...
The installation material must ensure the mechanical connection on a permanent basis.
The fixing points are designed for:
ƒ M6 cheese head, hexagon socket, acc. to DIN 912/ISO 4762
ƒ M6 cheese head, Torx, acc. to ISO 14579
g
3
g
3
h
g
3
c
3
d
3
r
g
4×
M6
r
g
3
b
1
b
X2
X3
t
EMDAG026
h b t b
1
c
3
d
3
g g
3
r Ý
[mm] [kg]
EMDxG5... 250 254 109 237 210 180 9 Ø 6.7 106 3.9
